GP-78 Elite Radio

Frequency Range (V) 137 173MHz Frequency Range (U) 400 470MHz Number of Channel 199 CTCSS 50 CTCSS 105 DCS Frequency Spacing 5.6.25.10.12.5.25KHz Modulation FM Mode of Operation Simplex or Semi-duplex Antenna Impedance 50Ω Operating Voltage DC7.2V Current Consumption Cathode darth-plate Operating Temperature -1 +55 Output power ≤5W Spurious emissions ≤-65dB Current Consumption ≤1.6A(transmit 4W) Maximum Deviation ≤±5KHz Sensitivity Adjust 2 20mV Frequency Stability ±5ppm Usable Sensitivity 0.2μv Audio Output ≥0.5w Audio Distortion ≤10% Audio Frequency Response 300 3000Hz Occupied Bandwidth ≤16KHz We will not advance,if changing the technique specification. FEATURE 1,Output power VHF5W/UHF4W 2,199groups for memory channels 3,Channel step (5/6.25/10/12.5/25KHZ) 4,VOX function 5,CTCSS/DCS 6,Multifunction scan 7,Three color for LCD to adjust
